About Beam Trammels
We are actively engaged in offering our clients the best in line Beam Trammels that are typically used in layout work to scribe circles and arcs. These trammels are the best replacement for the traditional divider or compass. Owing to its precision performance and usability, it is one of the most demanded tools in the marketplace. We have made available the Beam Trammels for our clients at the budget-friendly price range. And also, clients can get the product from us within the stipulated time frame
Specification :
HSN Code : 9017
| No. | Size of Beam (mm) | To Scribe Circle of Dia (mm) | Price Each |
| 251A | 265 | 450 | 900.00 |
| 251B | 365 | 650 | 1200.00 |
| 251C | 500 | 900 | 1800.00 |
Attachments
HSN Code : 9017
| No. | 251D | Per Set | 600.00 |
| No. | 251E | Per Set | 750.00 |
| No. | 251H | Per Set | 750.00 |
| No. | 251H | Per Set | 750.00 |
Heavy-Duty Performance for Precision TasksBuilt for reliability, these Beam Trammels are crafted from steel with corrosion-resistant, polished, and painted heads. Their secure knurled thumb screws ensure consistent accuracy during scribing and marking, even over expansive surfaces. Suitable for use with standard beams or rules, they deliver top-tier performance in demanding work environments.
Versatility and Ease of UseDesigned for compatibility and convenience, these trammels hold wooden beams or rules up to 2" wide. The replaceable hardened steel points guarantee a long service life, while the easy adjustment mechanism allows for swift setup and precise arc creation. This tool adapts to various project needs, delivering consistent results every time.
FAQ's of Beam Trammels:
Q: How do you adjust the arc diameter with these Beam Trammels?
A: To adjust the arc diameter, simply slide the trammel heads to the desired positions along a beam or rule-up to 2" wide-and secure them in place using the knurled thumb screws. The maximum arc is determined by the length of your chosen beam.
Q: What benefits do the hardened steel points and replaceable tips provide?
A: The hardened steel points enhance durability and offer precise scribing, even on tough surfaces. As the points are replaceable, maintenance is straightforward and cost-effective, extending the working life of your trammels.
Q: When should I use Beam Trammels instead of a standard compass?
A: Beam Trammels are ideal for marking large arcs or circles-typically beyond the width handled by a standard compass. Use them when your project demands accurate layout over several feet, such as in carpentry, metalworking, or construction.
Q: Where can these Beam Trammels be used effectively?
A: These trammels are suitable for workshops, construction sites, fabrication centers, and anywhere precise large-diameter marking or cutting is needed. Their compatibility with wooden beams or rules up to 2" wide broadens their application scope.
Q: What makes the adjustment mechanism of these trammels secure?
A: The knurled thumb screw lets you lock the heads firmly in place along the beam, ensuring they remain steady during use and allowing for repeatable, accurate layouts or markings.
Q: How do the corrosion-resistant and polished surfaces benefit the tool's longevity?
A: Polished and painted surfaces provide resistance to rust and corrosion, helping the trammels withstand harsh environments. This design choice preserves both function and appearance over years of repeated use.
