About Slotted Angle Plate
A Slotted Angle Plate is a precision work-holding accessory used in machining, inspection, and layout operations. Made from high-grade cast iron, it is accurately machined and ground to provide true flat surfaces at 90 angles. The slots on the plate allow easy clamping of workpieces, fixtures, or machine parts during drilling, milling, boring, or marking operations.
These plates ensure rigidity, accuracy, and repeatability, making them essential for tool rooms, workshops, and inspection departments.
Different sizes and categories are as follow:
| Dimensions (LxWxH) mm |
Open End No. |
Webbed No. |
| 88x75x63 |
300 |
200 |
| 112x88x75 |
301 |
201 |
| 150x125x112 |
302 |
202 |
| 175x138x112 |
303 |
203 |
| 200x150x125 |
304 |
204 |
| 225x175x150 |
305 |
205 |
| 250x200x150 |
306 |
206 |
| 300x225x200 |
307 |
207 |
High Accuracy and VersatilityCrafted to meet IS:2554-1971 standards, this slotted angle plate boasts high precision and repeatable accuracy, ensuring reliable measurements and optimal workpiece clamping. Its customizable sizing and variety of slot types provide adaptability for any inspection, machining, or assembly operation.
Robust Construction and Corrosion ResistanceMade from premium cast iron and finished in silver & black, this angle plate achieves 200-250 HB hardness. The corrosion-resistant surface finish extends operational lifespan while maintaining a sophisticated appearance, making it ideal for demanding industrial settings.
Application Across Multiple IndustriesSuitable for work holding, inspection, and machining, this angle plate is preferred by manufacturers, exporters, and traders across India. Its customizability, precision finish, and provided mounting holes make it a trusted tool in workshops and quality control departments alike.
FAQ's of Slotted Angle Plate:
Q: How is the slotted angle plate used in machining and inspection processes?
A: The slotted angle plate is utilized to securely hold workpieces in position during machining, assembly, or inspection. Its L-shaped design and precision slots enable flexible and stable clamping, facilitating accurate measurements and machining operations.
Q: What distinguishes this slotted angle plate from standard angle plates?
A: This angle plate offers both T-slots and parallel slots for enhanced clamping versatility. Its surface is precision ground to ensure high accuracy, and it is manufactured to IS:2554-1971 standards, providing reliability for critical industrial tasks.
Q: When should I choose a precision ground angle plate over a regular one?
A: Precision ground angle plates are preferred when high accuracy and repeatability are essential, such as during fine machining, inspection, and assembly of components where even slight deviations are unacceptable.
Q: Where are these slotted angle plates typically installed or used?
A: They are often employed in machine shops, manufacturing facilities, inspection departments, and workshops throughout India and globally. The mounting holes make them easy to fix to workbenches, machines, or inspection tables.
Q: What is the process used to ensure high accuracy and surface finish?
A: Each angle plate is manufactured from high-quality cast iron and then precision ground according to IS:2554-1971. This process achieves the required flatness, surface finish, and dimensional accuracy, ensuring dependable long-term performance.
Q: How do the T-slots and parallel slots benefit my clamping operations?
A: T-slots and parallel slots provide versatile options for positioning and securing clamps, fixtures, or workpieces, simplifying the setup and enhancing stability during machining or inspection.
Q: What are the primary benefits of using this corrosion-resistant, hardened cast iron angle plate?
A: The cast iron construction ensures sturdiness and vibration dampening, while the corrosion-resistant finish maintains durability over time. This combination guarantees reliable performance and longevity, even in challenging workshop environments.
