About C I Vee Block
A CI Vee Block (Cast Iron Vee Block) is a precision work-holding accessory used for supporting and holding cylindrical or round workpieces during inspection, marking, drilling, or machining operations. Manufactured from close-grained cast iron, it is accurately machined and ground to provide true flatness and right angles.
The V groove in the block ensures firm support for shafts, rods, or pipes, while the cast iron construction provides stability and durability. CI Vee Blocks are commonly used in tool rooms, workshops, and inspection departments for layout and measuring tasks.
Specification :
C.I. Vee Blocks (With & without clamps)
HSN Code : 8205
| Size mm | No. |
| 50x38x38 | 230 |
| 75x38x38 | 230B |
| 50x38x25 | 220 |
| 63x47x28 | 220A |
| 75x56x31 | 221 |
| 75x50x50 | 221A |
| 75x63x38 | 221B |
| 75x63x63 | 221C |
| 100x75x38 | 222 |
| 100x63x63 | 222A |
| 100x75x75 | 222B |
| 100x88x63 | 222C |
| 100x88x88 | 222D |
| 125x88x88 | 223 |
| 125x75x75 | 223A |
| 125x100x100 | 223B |
| 125x125x125 | 223C |
| 150x100x50 | 224 |
| 150x100x100 | 224A |
| 150x125x125 | 224B |
| 150x150x150 | 224C |
| 175x125x56 | 225 |
| 200x150x63 | 226 |
| 200x150x75 | 226A |
| 200x150x100 | 226B |
| 200x150x150 | 226C |
| 225x169x75 | 227 |
| 250x175x88 | 228 |
| 250x175x100 | 228A |
| 300x200x88 | 229 |
| 300x200x100 | 299A |
Robust Construction for Enhanced DurabilityMade from premium cast iron, the C I Vee Block offers exceptional strength and longevity, making it a reliable choice for repeated industrial use. Its robust design withstands rigorous environments, ensuring your operations continue smoothly and efficiently for years to come.
Precision Support for Workpiece StabilityDesigned to securely hold cylindrical objects during operations like inspection or machining, the C I Vee Block enhances accuracy and prevents slippage. With its precise dimensions and stable base, it supports high-quality results in engineering and manufacturing applications.
FAQ's of C I Vee Block:
Q: How is a C I Vee Block typically used in industrial settings?
A: A C I Vee Block is used to hold and support cylindrical objects securely during processes such as inspection, marking, or machining, ensuring accurate alignment and preventing movement.
Q: What material is the C I Vee Block made from, and what are its benefits?
A: It is made from robust cast iron, which offers durability, resistance to wear, and stability, making it ideal for heavy-duty industrial applications.
Q: When should I use a C I Vee Block in my workshop?
A: You should use a C I Vee Block whenever you need to stabilize round or irregularly shaped workpieces for precise measuring, marking, or machining tasks.
Q: Where is the C I Vee Block usually sourced from?
A: The C I Vee Block is available from reputable exporters, manufacturers, suppliers, and traders in India, known for their quality and reliability.
Q: What is the typical process for using a C I Vee Block?
A: Simply position your cylindrical workpiece within the groove of the Vee block and secure it as needed. This setup allows for stable, accurate work during inspection or machining.
Q: What size and dimensions does this C I Vee Block offer?
A: This model features a length of 50 mm, width and height of 38 mm, and is classified as size No. 230.
Q: What are the primary benefits of using a C I Vee Block?
A: The main benefits include improved precision, secure holding of workpieces, increased safety during machining, and long-lasting performance due to its cast iron construction.
